DIRECT DRIVE TRANSMISSION FOR IMPROVED POWER TRANSFER

• Precision-engineered twin parallel rotary screws deliver an efficient positive drive transmission.
• This negates slippage for greater power transfer and machine reliability compared to belt-driven compressors.
• It also reduces machine maintenance, component stress and lowers power consumption and energy costs.

VARIABLE SPEED 5.5KW MOTOR DELIVERS EVEN POWER DISTRIBUTION

• The inverter motor control enables automated soft-start and slope-down functionality.
• This ensures even torque distribution when powering up and controlled load descent once the receiver has reached the required air volume.
• The on-demand air production created adjusts to vary the amount of air delivered for greater versatility.
• These automated functions help to reduce machine wear and support long life use.
• Fitted with an IE4 motor for greater efficiency and lower energy costs.

SILENCED CABINET ENSURES REDUCED NOISE OPERATION

• Heavy-duty silenced cabinet minimises vibration and operates at reduced noise levels.

200LTR AIR RECEIVER SUPPORTS HIGH AIR CONSUMPTION

• Designed to safely store high volume compressed air, helping to ensure a stable flow and meet pressure peaks when in operation.

REAL-TIME DIAGNOSTIC COLOUR DISPLAY

• An intuitive colour touchscreen display provides real-time diagnostic information on the status of the compressor.
• Includes operation and load status, receiver pressure, motor voltage and internal temperature.

EASY ACCESS CABINET FOR MAINTENANCE & SERVICE

• All critical machine components are fully accessible through a single access cabinet panel, helping to reduce air production downtime.
• A service should be performed annually or after every 2000 loading hours.
• The compressor should perform a minimum of 1000 loading hours annually.

ALL-IN-ONE MACHINE DESIGN MINIMISES LOST WORK AREA SPACE

• The compact all-in-one design ensures a smaller overall footprint which helps to minimise lost work area space once the compressor is installed.
